Bluetooth receiver TELEC certification——ZRLK

Author:中認(rèn)聯(lián)科 time:2022-03-01 Ctr:1243

Bluetooth receivers refer to receivers that can accept the transmission mode of Bluetooth. They generally support PCs and Macs. They have been widely used in our lives today. For example, our commonly used Bluetooth headsets, Bluetooth speakers, Bluetooth mice, and Bluetooth keyboards all belong to Bluetooth. receiver. However, in general, if these Bluetooth smart products want to export to the Japanese market, they need to apply for TELEC certification.

Introduction to TELEC Certification

TELEC certification is also called MIC certification. TELEC (Telecom Engineering Center) is the main registration certification body for radio equipment compliance certification in Japan. MIC (Ministry of Internal Affairs and Communications) is a government agency that regulates radio frequency equipment in Japan. MIC is the Japanese Ministry of Internal Affairs and Communications, responsible for compiling regulations and standards. TELEC is only one of the designated issuing agencies for MIC, so it is called TELEC certification or MIC certification. TELEC certification is mandatory and the certification body is a registered certification body recognized by MIC in the scope of designated radio equipment.


TELEC certification standard

The technical standards of TELEC certification refer to the classification and technical standards of designated radio equipment listed in the technical regulations compliance certification system on its official website. It is worth noting that in the event of discrepancies between these technical standards and the technical requirements of the Radio Regulatory Commission Rules No.18, the Radio Regulations shall prevail.

Types of TELEC certification

1. Test Certification

The test certification is verified for each equipment unit, and the certification is only valid for each verified equipment unit.

2. Type Certification

Type approval refers to the verification of a sample of a batch of equipment of the same design and manufacture. The certification is valid for the batch of equipment, but if the design or manufacture of the equipment has changed, the equipment will need to be re-certified.

Bluetooth receiver TELEC certification test project

1. Frequency Error Measurement

2. Occupied Bandwidth and Spread-spectrum Bandwidth / Factor

3. Unwanted Emission Intensity Measurement

4. Antenna Power Error Measurement

5. Receiver spurious disturbance test (Limitation of Collateral Emission of Receiver Measurement)

6. Transmission Antenna Gain (EIRP Antenna Power) Measurement

7. Transmission Radiation Angle Width (3dB Beamwidth) Measurement

8. Duty Cycle Measurement

9. Retention time test

Bluetooth receiver TELEC certification process

1. to submit an application;

2. Sign the quotation and fill in the certification application form;

3. Provide samples and provide technical information, and pay the first payment;

4. The laboratory starts the test after receiving the sample;

5. After the test is OK, issue a report;

6. Submit the report to the TELEC agency to apply for the TELEC certificate;

7. The customer pays the balance;

8. TELEC certificate (also called MIC certificate) will be issued after the case is over.


Please contact our company ZRLK for Bluetooth receiver TELEC certification. We will provide you with professional and efficient testing and certification services with favorable prices and considerate service. If you provide us with product pictures and specifications, we will give you corresponding cycles, quotations and specific solutions according to your products. You are welcome to inquire!
